5.35ton Excavator WYL5.6



Quick Details

Feature: Excavator

Condition: New

Application: Construction

Brand Name: YUGONG

Model Number: WYL5.6

Certification: ISO,CE

Rated Loading Capacity: 5.35t

Bucket Capacity: 0.25m3

Dimension:  7940*2200*2900mm

Max. Lifting Load: 5.35t

Engine: YTR4108

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Color: Blue

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

7~15 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

WYL5.6

Overall length (Transportation)

mm

7940

Overall width (Transportation)

mm

2200

Overall height (Transportation)

mm

2900

Weight





Total weight

kg

5350

Power





Engine model



YTR4108

Engine rated power

kW

74.9

Engine rated speed

r/min

2200

Travel





Travel speed

km/h

40

Main performance





Rated load

t

5.35

Bucket capacity

m3

0.25

Gradeability

0



Hydraulic system pressure

Mpa

20

Bucket digging force

KN



Arm digging force

KN



Max. tractive force

KN



Max. dumping clearance

m

4.75

Max. digging depth

m

3.4

Max. digging radius

m

5.95

Max. digging height

m

6.45

Back-end swing radius

m

9

Steering speed

r/min



Wheel tread

m

1.65

Wheel base

m

2.76

Tire models



9.00-20

Min. ground clearance

m
