24.54ton Bulldozer B230



Quick Details

Feature: Bulldozer

Condition: New

Application: Construction

Brand Name: LIUGONG

Model Number: B230

Certification: ISO,CE

Gradeability: 300

Bucket Capacity: 7.8m3

Dimension:  5500*2560*3438mm

Ground pressure: kpa

Engine: NT855-C280S10

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Color: Yellow

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

7~15 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

B230

Overall length

mm

5500

Overall width

mm

2560

Overall height

mm

3438

Ground contact length of track

mm



Track shoe width

mm

560

Weight





Total weight

kg

24540

Power





Engine model



NT855-C280S10

Engine rated power

kW

169

Engine rated speed

r/min

2000

Travel





Travel speed 1st (forward/backward)

km/h

0~3.8/0~4.9

Travel speed 2st (forward/backward)

km/h

0~6.8/0~8.5

Main performance





Operation weight

t

24.54

Blade capacity

m3

7.8

Gradeability

0

30

Ground pressure

kpa



Shovel blade width

m

3.725

Shovel blade height

m

1.395

Max. hoisting height

m

1.21

Max. digging depth

m

0.54

Max. gradient

m



Track gauge

m



Caterpillar track pitch

m



Min. swing radius

m

3.3

Min. ground clearance

m

0.405
