26ton Road Roller XS263



Quick Details

Feature: Road Roller

Condition: New

Application: Construction

Brand Name: XCMG

Model Number: XS263

Certification: ISO,CE

Operation Weight: 26t

Static Linear Pressure: 784N/cm

Dimension: 6877*2430*3330mm

Travel Speed: 0~10.4km/h

Vibration Frequency: 27/32Hz

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Theoretical Amplitude: 1.9/0.95mm

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

7~15 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

XS263

Overall length

mm

6877

Overall width

mm

2430

Overall height

mm

3330

Weight





Total weight in travel

kg

26000

Load on front drum

kg

17000

Load on rear wheels

kg

9000

Power





Engine model



BF6M1013EC

Engine rated power

kW

157

Engine rated speed

r/min

2000

Fuel oil consumption

g/kW·h

218

Travel





Travel speed 1st

km/h

0~3.4

Travel speed 2st

km/h

0~5

Travel speed 3st

km/h

0~5.2

Travel speed 4st

km/h

0~10.4

Main performance





Drum diameter

mm



Drum width

mm



Static linear load

N/cm

784

Vibration frequency (Low / High)

Hz

27/32

Theoretical amplitude (High / Low)

mm

1.9/0.95

Excitation force (High / Low)

kN

410/300

Compacting width

mm

2130

Min. turning diameter

m

6964

Min. ground clearance

mm

457

Steering angle

°



Oscillating angle

°



Theoretical gradeability

%

50

Wheel base

mm

6964
