68ton Rotary Drilling Rig XR200



Quick Details

Feature: Rotary Drilling Rig

Condition: New

Application: Construction

Brand Name: XCMG

Model Number: XR200

Certification: ISO,CE

Total weight: 68t

Rated power: 246kw

Dimension: 10200*4400*20850mm

Drilling depth: 60m

Max. hoisting power: 180KN

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Max. hoisting / lowering speed: 65m/min

After-sales Service Provided: Engineers available to service machinery overseas


Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

10 days


Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

XR200

Overall length

mm

10200

Overall width

mm

4400

Overall height

mm

20850

Weight





Total weight in travel

kg

68000

Power





Engine model



CUMMIN M11-C330

Engine rated power

kW

246

Engine rated torque

KN.m

200

Travel





Max. traveling speed

km/h

1.5

Main performance





Rotary speed

r/min

7~22

Max. pulling speed (main winch)

m/min

≥65

Max. pulling speed (auxiliary winch)

m/min

≥60

Max. pulling force (main winch)

KN

180

Max. pulling force (auxiliary winch)

KN

80

Max. pull-down piston push

KN

180

Max. pull-down piston pull

KN

180

Max. pull-down piston stroke

m

5.0

Working pressue

Mpa

30

Distance between tracks

mm

3500~4400

Min. clearance

mm

468

Max. grade ability

%

40
