Quick Details Feature: Rough Terrain Crane Condition: New Application: Construction Brand Name: ZOOMLION Model Number: RT550 Certification: ISO,CE Rated Loading Capacity: 55t Rated Lifting Moment: 1967kN.M Dimension: 13100×3300×3750mm Max. Lifting Load: 55t Max. Lifting Height: 34.8m Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Span: 6.9/6.9m After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 10 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit RT550 Overall length mm 13100 Overall width mm 3300 Overall height mm 3750 Weight Total weight in travel kg 39200 Front axle load kg 20440 Rear axle load kg 18760 Power Engine model CumminsQSB6.7 Engine rated power kW/(r/min) 160/2200 Engine rated torque N.m/(r/min) 888/1400 Travel Max. travel speed km/h 39 Min. turning diameter m Min. ground clearance mm Approach angle ° Departure angle ° Max. grade ability % 110 Fuel consumption for 100km L Main performance Max. rated total lifting capacity t 55 Min. rated working radius m Turning radius at turntable tail m Max. lifting torque kN.m 1967 Base boom m 10.8 Fully extended boom m 34 Fully extended boom+ jib m 51 Longitudinal outrigger span m 6.9 Lateral outrigger span m 6.9 Working speed Boom luffing time s 56 Boomfull extension time s 100 Max. swing speed r/min 0~2.5 Max. speed of main winch (single rope) (no load) m/min 150 Max. speed of aux. winch (single rope) (no load) m/min
Feature: Rough Terrain Crane
Condition: New
Application: Construction
Brand Name: ZOOMLION
Model Number: RT550
Certification: ISO,CE
Rated Loading Capacity: 55t
Rated Lifting Moment: 1967kN.M
Dimension: 13100×3300×3750mm
Max. Lifting Load: 55t
Max. Lifting Height: 34.8m
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Span: 6.9/6.9m
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
10 days
Dimension Unit RT550 Overall length mm 13100 Overall width mm 3300 Overall height mm 3750 Weight Total weight in travel kg 39200 Front axle load kg 20440 Rear axle load kg 18760 Power Engine model CumminsQSB6.7 Engine rated power kW/(r/min) 160/2200 Engine rated torque N.m/(r/min) 888/1400 Travel Max. travel speed km/h 39 Min. turning diameter m Min. ground clearance mm Approach angle ° Departure angle ° Max. grade ability % 110 Fuel consumption for 100km L Main performance Max. rated total lifting capacity t 55 Min. rated working radius m Turning radius at turntable tail m Max. lifting torque kN.m 1967 Base boom m 10.8 Fully extended boom m 34 Fully extended boom+ jib m 51 Longitudinal outrigger span m 6.9 Lateral outrigger span m 6.9 Working speed Boom luffing time s 56 Boomfull extension time s 100 Max. swing speed r/min 0~2.5 Max. speed of main winch (single rope) (no load) m/min 150 Max. speed of aux. winch (single rope) (no load) m/min
Dimension
Unit
RT550
Overall length
mm
13100
Overall width
3300
Overall height
3750
Weight
Total weight in travel
kg
39200
Front axle load
20440
Rear axle load
18760
Power
Engine model
CumminsQSB6.7
Engine rated power
kW/(r/min)
160/2200
Engine rated torque
N.m/(r/min)
888/1400
Travel
Max. travel speed
km/h
39
Min. turning diameter
m
Min. ground clearance
Approach angle
°
Departure angle
Max. grade ability
%
110
Fuel consumption for 100km
L
Main performance
Max. rated total lifting capacity
t
55
Min. rated working radius
Turning radius at turntable tail
Max. lifting torque
kN.m
1967
Base boom
10.8
Fully extended boom
34
Fully extended boom+ jib
51
Longitudinal outrigger span
6.9
Lateral outrigger span
Working speed
Boom luffing time
s
56
Boomfull extension time
100
Max. swing speed
r/min
0~2.5
Max. speed of main winch (single rope) (no load)
m/min
150
Max. speed of aux. winch (single rope) (no load)
