Quick Details Feature: Wheel Loader Condition: New Application: Construction Brand Name: SDLG Model Number: LG989 Certification: ISO,CE Rated Loading Capacity: 8.0t Bucket Capacity: 3.5~6.0m3 Dimension: 9300×3320×3725mm Max. Lifting Load: 8.0t Engine: D13-15185586-8T Place of Origin: Jiangsu, China (Mainland) Warranty: 1 year Color: Yellow After-sales Service Provided: Engineers available to service machinery overseas Packaging & Delivery Packaging Details: Nude package Shipped by Ro-Ro or Bulk shipment Delivery Detail: 7~15 days Main Features 1. More excellent performance 2. More reliable quality 3. Easier to operate 4. Easier to maintain 5. More energy-efficient and environmental friendly Technical Parameters Dimension Unit LG989 Overall length mm 9300 Overall width mm 3320 Overall height mm> 3725 Weight Total weight kg 26500～28000 Power Engine model D13-15185586-8T Engine rated power kW 245 Engine rated speed r/min 2100 Travel Travel speed 1st (forward/backward) km/h 0~6.7 Travel?speed 2st (forward/backward) km/h 0~12.4 Main performance Rated load t 8.0 Bucket capacity m3 3.5~6.0 Dumping clearance m 3.33 Dumping reach m 1.39 Max. breakout force KN ≥244 Max. traction force KN ≥225 Articulation angle 0 45 Gradeability 0 27 Wheel base m 3.55 Tread m 2.42 Tyre size m Min. ground clearance m 0.566 Min. turning radius m 6.739 Working speed Hydraulic cycle time – raise s Total hydraulic cycle time s ≤12
Feature: Wheel Loader
Condition: New
Application: Construction
Brand Name: SDLG
Model Number: LG989
Certification: ISO,CE
Rated Loading Capacity: 8.0t
Bucket Capacity: 3.5~6.0m3
Dimension: 9300×3320×3725mm
Max. Lifting Load: 8.0t
Engine: D13-15185586-8T
Place of Origin: Jiangsu, China (Mainland)
Warranty: 1 year
Color: Yellow
After-sales Service Provided: Engineers available to service machinery overseas
Packaging Details:
Nude package Shipped by Ro-Ro or Bulk shipment
Delivery Detail:
7~15 days
Dimension Unit LG989 Overall length mm 9300 Overall width mm 3320 Overall height mm> 3725 Weight Total weight kg 26500～28000 Power Engine model D13-15185586-8T Engine rated power kW 245 Engine rated speed r/min 2100 Travel Travel speed 1st (forward/backward) km/h 0~6.7 Travel?speed 2st (forward/backward) km/h 0~12.4 Main performance Rated load t 8.0 Bucket capacity m3 3.5~6.0 Dumping clearance m 3.33 Dumping reach m 1.39 Max. breakout force KN ≥244 Max. traction force KN ≥225 Articulation angle 0 45 Gradeability 0 27 Wheel base m 3.55 Tread m 2.42 Tyre size m Min. ground clearance m 0.566 Min. turning radius m 6.739 Working speed Hydraulic cycle time – raise s Total hydraulic cycle time s ≤12
Dimension
Unit
LG989
Overall length
mm
9300
Overall width
3320
Overall height
mm>
3725
Weight
Total weight
kg
26500～28000
Power
Engine model
D13-15185586-8T
Engine rated power
kW
245
Engine rated speed
r/min
2100
Travel
Travel speed 1st (forward/backward)
km/h
0~6.7
Travel?speed 2st (forward/backward)
0~12.4
Main performance
Rated load
t
8.0
Bucket capacity
m3
3.5~6.0
Dumping clearance
m
3.33
Dumping reach
1.39
Max. breakout force
KN
≥244
Max. traction force
≥225
Articulation angle
0
45
Gradeability
27
Wheel base
3.55
Tread
2.42
Tyre size
Min. ground clearance
0.566
Min. turning radius
6.739
Working speed
Hydraulic cycle time – raise
s
Total hydraulic cycle time
≤12
