1.7ton Backhoe Loader 630

Quick Details

Feature: Wheel Loader

Condition: New

Application: Construction

Brand Name: SINOMACH

Model Number: 630

Certification: ISO,CE

Rated Loading Capacity: 1.7t

Bucket Capacity: 1.0m³

Dimension: 7085*2313*3424mm

Max. Lifting Load: 1.7t

Engine: 4BTA3.9-C110

Place of Origin: Jiangsu, China (Mainland)

Warranty: 1 year

Color: Yellow

After-sales Service Provided: Engineers available to service machinery overseas

Packaging & Delivery

Packaging Details:

Nude package Shipped by Ro-Ro or Bulk shipment

Delivery Detail:

7~15 days

Main Features

1. More excellent performance
2. More reliable quality
3. Easier to operate
4. Easier to maintain
5. More energy-efficient and environmental friendly

Technical Parameters

Dimension

Unit

630

Overall length

mm

7085

Overall width

mm

2313

Overall height

mm

3424

Weight

　

　

Total weight

kg

7250

Power

　

　

Engine model

　

4BTA3.9-C110

Engine rated power

kW

82

Engine rated speed

r/min

2200

Travel

　

　

Travel speed 1st (forward/backward)

km/h

6/6

Travel?speed 2st (forward/backward)

km/h

9.6/9.6

Main performance

　

　

Rated load

t

1.7

Bucket capacity

m³

1.0

Dumping clearance

m

2.714

Dumping reach

m

0.845

Max. breakout force

KN

>60

Max. traction force

KN

70±5%

Steering angle

⁰

Gradeability

⁰

30

Wheel base

m

2.1555

Tread

m

1.7/1.88

Tyre size

m

Min. ground clearance

m

0.275

Min. turning radius

m

4.38

Working speed

　

　

Lifting time of loading bucket

s

4.5

Lowering time of loading bucket

s

3.5
